Flexible cable 7x2.5 black numbered wires 10696

Index local:
KLB214HELU
Numéro de catalogue:
10696
Code EAN:
4060892004742
Producteur: HELUKABEL
Number of veins: 7
Color: Black
Vein material: Copper
Prix:
10,82 zł
gross / mc.
(y compris la TVA 23%)
Livraison en 3h
Accessible 2 mc.
Ramassage en 1h
Quantité mc.
(plusieurs:
1
)
Ajouter à la demande de devis
Ajouter au presse-papiers
Imprimer

Description du produit


JZ-600 7G2.5mm2 flexible cable 0.6/1 kV black conductors numbered 10696 Helukabel

Control cable made of special PVC, compliant with DIN VDE 0262/12.95 and DIN VDE 0281 vol. 13, regarding the insulation thickness for the operating voltage of 1 kV

Temperature range:

flexible    -5°C to +80°C

stationary -40 °C to +80°C

Working voltage: U0/U 0.6/1 kV

Test voltage: 4000 V

Breakdown voltage : min. 8000 V

Insulation resistance:

min. 20 Mm x km

Current capacity: according to DIN VDE 0298

Minimum bending radius:

7.5 x cable Ø
< br/>with fixed installation 4 x cable Ø

Radiation resistance:

up to 80 x 106 cJ/kg (up to 80 Mrad)

Possibility of laying directly in the ground for cables with an outer diameter of more than 18 mm. For conditions of particular exposure to vibration or high ground moisture, industry recommendations apply.

Données techniques

  • Number of veins
    7
  • Vein material
    Copper
  • Vein designation
    numbered
  • Core
    Cord
  • Nominal cross section [mm2]
    2.5
  • Insulation material
    PVC
  • Color
    Black
  • Rated voltage [V]
    300/500
  • Core cross-section [mm²]
    2.5
  • Outer diameter [mm]
    13.8
  • Accurate color
    RAL 9005
  • PKWIU
    27.32.13.0

Détails du fabricant

  • Producteur
    HELUKABEL Polska Sp. z o.o.
  • Adresse
    96-325 Radziejowice Krze Duże 2 Polska
