Flexible cable 5x10 black numbered wires 10722

Indice locale:
KLB680HELU
Numero di catalogo:
10722
Codice EAN:
4060892005008
Produttore: HELUKABEL
Number of veins: 5
Color: Black
Vein material: Copper
Prodotto di grandi dimensioni
Prezzo:
80,47 zł
gross / metro
(inclusa IVA 23%)
Esaurito
Su ordinazione
Aggiungi alla richiesta di preventivo
Stampa

Descrizione del prodotto

Used for medium mechanical loads for flexible connections where there are no tensile stresses. Usually installed in dry, damp and wet rooms, and outdoors (permanently installed). It can be laid directly in the ground when the thickness of the outer diameter is equal to or greater than 18 mm. Used in the engineering and metallurgical industries, for control, signaling and measurements at production lines, internal installations, air-conditioning installations, in metallurgy and steelworks. The veins are numbered in such a way that even a slight exposure of the outer dura allows the location of the vein to avoid confusion, the markings are underlined. A protective vein located close to the outer sheath. Outer tire made of special black PVC, UV-resistant. The cable is mainly used in the countries of Southern Europe, Eastern Europe and Arab countries. CE = The product complies with the requirements of the Low Voltage Directive 2006/95/EC.

Dati tecnici

  • Number of veins
    5
  • Vein material
    Copper
  • Core cross-section [mm²]
    10
  • Accurate color
    RAL 9005
  • PKWIU
    27.32.13.0
  • Color
    Black
  • Rated voltage [V]
    300/500
  • Core
    Cord
  • Insulation material
    PVC

Dettagli del produttore

  • Produttore
    HELUKABEL Polska Sp. z o.o.
  • Indirizzo
    96-325 Radziejowice Krze Duże 2 Polska
