Flexible cable 4x1.5 colored wires 11080

Index local:
KSA017HELU
Numéro de catalogue:
11080
Code EAN:
4060892006203
Producteur: HELUKABEL
Number of veins: 4
Color: Gray
Vein material: Copper
5
24
zł
gross / mc.  (y compris la TVA 23%)
Disponibilité
Dostępne 20 mc.
Vérifier
Odbiór!
Odbierz w godzinę!
Détails
Twoja hurtowinia
Dostępność w oddziale
Choisissez votre grossiste
Sélectionner
Quantité mc. (plusieurs: 1 )
Ajouter à la demande de devis
Ajouter au presse-papiers
Imprimer

Description du produit

Used for medium mechanical loads for flexible connections where there are no tensile stresses. Usually laid in dry, damp and wet rooms, but not in the open air. Used in the engineering and metallurgical industries, for control, signaling and measurements at conveyors and technological lines. A protective vein located close to the outer sheath. The specially selected PVC mix guarantees excellent flexibility and rational, quick installation. CE = The product complies with the requirements of the Low Voltage Directive 2006/95/EC.

Données techniques

  • Number of veins
    4
  • Vein material
    Copper
  • Vein designation
    colors
  • Core
    Cord
  • Nominal cross section [mm2]
    1.5
  • Insulation material
    PVC
  • Color
    Gray
  • Rated voltage [V]
    300/500
  • Core cross-section [mm²]
    1.5
  • Outer diameter [mm]
    7.4
  • Accurate color
    Gray
  • PKWIU
    27.32.13.0

Détails du fabricant

  • Producteur
    HELUKABEL Polska Sp. z o.o.
  • Adresse
    96-325 Radziejowice Krze Duże 2 Polska
