Twilight modular relay with sensor 1Z 16A 24V AC/DC 1-100lx IP20/IP54 113100240000

Name: Twilight modular relay with sensor 1Z 16A 24V AC/DC 1-100lx IP20/IP54
Brand: FINDER
SKU: APF017FIND
Price: 245.90 PLN
Availability: BackOrder

local index:

APF017FIND

Catalog number:

113100240000

EAN code:

8012823362564

Twilight modular relay with sensor 1Z 16A 24V AC/DC 1-100lx IP20/IP54

Click on the photo to enlarge

Manufacturer: FINDER

Contact material: AgSnO2

Installation: On the TH-35 rail

AC coil voltage [V]: 12-24

See full description

Price:

245,90 zł

gross / pcs.

(including VAT 23%)

2 weeks

On request

Quantity pcs.

(multiplicity:

1

)

Add to inquiry

Add to clipboard

Print

Ask about the product

Product description Technical data Manufacturer details Bulk packaging

Product description

Relays for automatic lighting control depending on the level of external light intensity – with a separate light sensor.

Technical data

Contact material

AgSnO2
AC coil voltage [V]

12-24
Rated voltage [V]

230
Power consumption [VA]

2.5
Rated current [A]

16
Level of security

IP20/IP54
Rated inrush current [A]

thirty
Type of coil voltage

AC/DC
Rated switching power for AC1 [VA]

4000
Electrical durability AC1 [number of cycles]

100000
Tripping time [s]

15

Installation

On the TH-35 rail
DC coil voltage [V]

12-24
Overvoltage resistance [kV]

3
Power consumption [W]

0.9
Family

11
Width [number of modules]

1
Number of contacts

1Z
Rated AC switching voltage [V]

400
Rated switching power for AC15 (230V AC) [VA]

750
Sensitivity setting range [lx]

1-100
Return time [s]

thirty

Other technical data

Rated voltage

24 V
Max. incandescent lamp load

2000 W
Max. load fluorescent lamp (Duo circuit)

1000 VA
Max. switching current (cos phi = 0.6)

12 A
Adjustment range brightness value

1 ... 100 lx
Push button input

Yes
Max. conductor length light sensor

50 m
Mounting method light sensor

Naścienny
Width in number of modular spacings

1
Degree of protection (IP)

IP20

Rated frequency

50 ... 60 Hz
Max. load fluorescent lamp

1000 VA
Max. load fluorescent lamp (parallel compensated)

750 VA
Rated switch current

16 A
With programmable overnight shutoff

Yes
Rated voltage light sensor

5 V
Protection class light sensor

III
Mounting method

DIN rail
Built-in depth

60.8 mm
Degree of protection (IP) light sensor

IP54

Manufacturer details

Manufacturer

Finder S.p.A. con unico socio
Address

10040 Almese Via Drubiaglio 14 Włochy
E-mail

finder.pl@findernet.com

Bulk packaging

A kind of package	Sztuka	Sztuka	Paczka
Quantity	1 pcs.	5 pcs.	5 pcs.
Weight (kg)	0,146	0,845	-
Width (m)	0,092	0,275	-
Length (m)	0,053	0,095	-
Depth (m)	0,157	0,165	-
