Twilight automaton with an internal AZH photosensitive sensor AZH-24V

Name: Twilight automaton with an internal AZH photosensitive sensor
Brand: F&F
SKU: APF106FIFQ
Price: 80.59 PLN

local index:

APF106FIFQ

Catalog No:

AZH-24V

EAN code:

5908312592303

Twilight automaton with an internal AZH photosensitive sensor

Click on the photo to enlarge

Manufacturer: F&F

Depth [mm]: 26

Power [W]: 0.56

Rated voltage [V]: 24

See full description

Price:

80,59 zł

gross / pcs.

(including VAT 23%)

Delivery in 3h

up to 2 weeks (business days)

Pickup in 1h

Quantity pcs.

(multiplicity:

1

)

Add to inquiry

Add to clipboard

Print

Ask about the product

Product description Technical data Manufacturer details Bulk packaging Files to download

Product description

Hermetic automatic lighting control. Equipped with an adjustable photosensitive sensor that allows you to set the level of sunlight intensity to turn the lighting on or off. It is perfect as a control module for lamps in shop windows, exhibitions, squares and streets.

Technical data

Depth [mm]

26
Rated voltage [V]

24
ON delay [s]

1-15
Width [mm]

67
Height [mm]

50
Package width [mm]

67
PKWIU

27.12.23.0

Power [W]

0.56
Delay [s]

10-30
load current [A]

10
Working temperature [°C]

-25-50
Package height [mm]

50
Package weight [kg]

0.2

Other technical data

Type of sensor

Built-in light sensor
Engaging brightness

2 ... 1000 lx
Switch-off delay

20 s
Max. switching power

2500 W
Suitable for C-load

No
Material

Plastic
Halogen free

Yes
Colour

Grey
Nominal voltage

24 V
Operating temperature

-25.00000000 ... 50.00000000 °C
Width

51 mm
Depth

25.5 mm
Min. depth of built-in installation box

0 mm

Contacts

1 make contact (NO)
Switching-off brightness

2.00000000 ... 1000.00000000 lx
Switching-on delay

10 s
Max. switching power LED

150 W
Mounting method

Surface mounted
Material quality

Thermoplastic
Surface protection

Untreated
RAL-number (similar)

7035
Max. switching current (resistive load)

10 A
Suitable for degree of protection (IP)

IP65
Height

67 mm
Diameter

0 mm

Manufacturer details

Manufacturer

F&F Filipowski S.K.
Address

95-200 Pabianice Konstantynowska 79/81 Polska
E-mail

biuro@fif.com.pl

Bulk packaging

A kind of package	Sztuka
Quantity	1 pcs.
Weight (kg)	0,107
Width (m)	0,031
Length (m)	0,095
Depth (m)	0,070
