TRS 24VUC 2CO Switching Relay, Catalog No. 1123500000 1123500000

Name: TRS 24VUC 2CO Switching Relay, Catalog No. 1123500000
Brand: WEIDMULLER
SKU: APE027WEID
Price: 75.13 PLN
Availability: BackOrder

Índice local:

APE027WEID

Número de catálogo:

1123500000

Código EAN:

4032248905287

TRS 24VUC 2CO Switching Relay, Catalog No. 1123500000

Haga clic en la foto para ampliar

Fabricante: WEIDMULLER

Precio:

75,13 zł

gross / uds.

(IVA incluido 23%)

2 semanas

Por encargo

Cantidad uds.

(múltiple:

1

)

Añadir a solicitud de presupuesto

Añadir al portapapeles

Imprimir

Pregunta por el producto

Datos técnicos Detalles del fabricante

Datos técnicos

Otros datos técnicos

Type of electric connection

Screw connection
With detachable clamps

No
Rated control supply voltage AC 50 Hz

26.4 ... 21.6 V
Rated control supply voltage DC

21.6 ... 26.4 V
Drive, polarization

Polarity free
Number of contacts as normally closed contact

0
Number of contacts as change-over contact

2
With forced-guided contacts

No
Material of contact surface

Nickel
Operating voltage AC 60 Hz

250 ... 250 V
Nominal current

8 A
Width

12.8 mm
Depth

87.8 mm

Complete with socket

Yes
With LED indication

Yes
Rated control supply voltage AC 60 Hz

21.6 ... 26.4 V
Voltage type for actuating

AC
Drive, switching attitude

Mono stable
Number of contacts as normally open contact

0
Type of switch contact

Single contact
Material contact

Silver nickel (AgNi)
Operating voltage AC 50 Hz

250 ... 250 V
Operating voltage DC

250 ... 250 V
Degree of protection (IP)

IP20
Height

89.6 mm
