Click on the photo to enlarge

F&F

Temperature controller RT-825 RT-825

local index:
APT034FIFQ
Catalog No:
RT-825
EAN code:
5908312592624
Price:
54,13 €
gross / pcs.
including VAT 23%
Availability:
up to a week (working days)
Delivery:
From 3,69 € (prepaid courier) Details
Quantity:
Goods at a promotional price can only be purchased in the quantity available in stock pcs.
Delivery methods:
Metody dostawy
details
Payment methods:
Metody płatności
details

Product description

The RT-825 temperature controller is designed for direct control of heating devices powered by 230V, with a maximum current not exceeding 16A.
Antifreeze temperature adjustment range0-10
Type of temperature sensorsNTC



Technical data

  • Depth [mm]
    22
  • Power [W]
    0.8
  • Rated voltage [V]
    230
  • connection
    1.5mm screw terminals
  • External probe
    RT-45
  • Width [mm]
    83.5
  • Height [mm]
    83.5
  • Package height [mm]
    83.5
  • Package weight [kg]
    0, 2
  • Hysteresis
    1
  • Installation
    Flush-mounted
  • load current [A]
    <16
  • Family
    F&HOMERADIO
  • Contact
    1Z separated
  • Working temperature [°C]
    -5-50
  • Temperature adjustment range [°C]
    5-60
  • Package width [mm]
    85

Other technical data

  • Model
    On/Off
  • Connection
    2-wire
  • Measuring range
    6 ... 0 °C
  • Control characteristic
    P
  • Number of heater outputs
    1
  • Number of cooler outputs
    0
  • Temperature readable
    no
  • Sensor/feeler type
    Resistance sensor
  • With display
    yes
  • Contact type
    Normally open contact (NO)
  • Max. contact load
    16 A
  • Explosion-proof
    no
  • Height
    86 mm
  • Depth
    22 mm
  • Type of power supply
    230 V AC
  • With receiver
    no
  • External sensor
    yes
  • Suitable for heating
    yes
  • Suitable for cooling
    no
  • Adjustable differential
    no
  • With sound indicator
    no
  • Mounting method
    Flush-mounted
  • Operation
    Button
  • Max. contact voltage
    230 V
  • Degree of protection (IP)
    IP20
  • Colour
    White
  • Width
    86 mm
  • Standby power consumption (solstandby)
    0.8 W
