Features - Maximum system expansion up to 44 I/O with 3 modules of 8 points each (4 inputs, 4 outputs), 1 analog input module, 1 temperature module (PT-100), 2 analog output modules, 1 communication module
- Possibility of extending the analog input to 8 points, of which 4 are 12-bit
- Available communication modules: Profibus-DP, DeviceNet, Modbus RTU, Ethernet TCP/IP.
- Built-in 16x4 display LCD
- Menu in Polish, English, French, Spanish, Italian, German and Portuguese.
- Programming from the keyboard or PC software
- Up to 300 rungs in LADDER language
- Up to 260 blocks in FBD language
- High-speed counter input (1kHz) and pulse output
- Built-in 31 Timer, 31 counters, 31 RTC, 126 pins in auxiliary, analog comparator
- Built-in RTC operation time (summer/winter time) is about 240 hours after power off.
- Outputs: relay - max 8A/point, transistor - max 0.5A/point .
- Ability to set security passwords – 2 levels
- 2 PWM outputs available (one can be used as PLSY- pulse at 1kHz)

Advantages:
→ compact dimensions
→ mounting on a TH-35 rail
→ LCD
→ the ability to program withóbuttons on the controller or via a PC
→ controller power supply 24VDC or 100-240VAC
→ additional expansion modules
→ free software

Installation

On the TH-35 rail
Level of security

IP20
PKWIU

27.12.31.0

Wire

AWG 12/3.5mm2
Humidity

5 - 90% RH

Other technical data

Supply voltage AC 50 Hz

100 ... 240 V
Voltage type (supply voltage)

AC
Max. number of time switches

31
Number of digital inputs

12
Supporting protocol for Modbus

Yes
Rail mounting possible

Yes
Width

126 mm
Depth

59.6 mm

Supply voltage AC 60 Hz

100 ... 240 V
Number of relay outputs

8
Model

Modular
Number of digital outputs

8
With display

Yes
Wall mounting/direct mounting

Yes
Height

90 mm

A kind of package	Pudełko	Pudełko
Quantity	1 pcs.	20 pcs.
Weight (kg)	0,445	7,600
Volume (m3)	0,001	-
Width (m)	0,140	0,340
Length (m)	0,065	0,287
Depth (m)	0,100	0,218
