Power supply control lamp - single-phase LK-712 G 10-30V LK-712G-10-30V

local index:
API018FIFQ
Catalog No:
LK-712G-10-30V
EAN code:
5908312591177
Manufacturer: F&F
Power [W]: 1
Installation: On the TH-35 rail
Charging current [A]: 0.5
Price:
8,13 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Indicator lamp LK-712 B 130-260V Intended use The indicator lamp LK-712 is used for optical signaling of the presence of voltage in the electric circuit. Operation The presence of voltage in the circuit is indicated by LED lighting.

Technical data

  • Power [W]
    1
  • Charging current [A]
    0.5
  • connection
    2.5mm screw terminals
  • Dimensions
    1 module (18mm)
  • Package width [mm]
    20
  • Operating voltage range [V]
    15-30
  • Installation
    On the TH-35 rail
  • contact gap [kV]
    3
  • Working temperature [°C]
    -25-50
  • Package height [mm]
    150
  • Package weight [kg]
    0.1
  • PKWIU
    27.40.24.0

Other technical data

  • Colour calotte
    Green
  • Lamp socket
    Other
  • Rated voltage
    30 V
  • Built-in depth
    65 mm
  • Lamp type
    LED
  • Max. lamp power
    0.8 W
  • Voltage type
    AC/DC
  • Degree of protection (IP)
    IP20

Bulk packaging

A kind of package Sztuka
Quantity 1 pcs.
Weight (kg) 0,043
Width (m) 0,019
Length (m) 0,095
Depth (m) 0,070
