Plastic inductive sensor 1NO/1NC 12-48V DC screw terminals XS8C4A1DPP20
Lokaler Index:
API365SCHN
Katalognummer:
XS8C4A1DPP20
EAN-Code:
3389119058421
Hersteller:
SCHNEIDER ELECTRIC
Material: Plastic
Preis:
985,24 zł
gross / stk.
(inklusive MwSt 23%)
Zur Angebotsanfrage hinzufügen
Drucken
Fragen Sie nach dem Produkt
Produktbeschreibung
Plastic inductive sensor 1NO/1NC 12-48V DC screw terminals
Technische Daten
-
MaterialPlastic
-
PKWIU26.51.66.0
Weitere technische Daten
-
Width sensor117 mm
-
Length of sensor40 mm
-
Switching distance20 mm
-
Type of switch functionProgrammable/configurable
-
Number of semiconductor outputs with signalling function1
-
Number of protected semiconductor outputs1
-
Type of actuationMetallic Target
-
Type of interface for safety communicationNone
-
Coating housingOther
-
SIL according to IEC 61508None
-
Max. output current at protected output100 mA
-
Rated control supply voltage DC12 ... 48 V
-
Switching frequency300 Hz
-
Housing materialPlastic
-
Explosion safety category for gasNone
-
Interference resistance to magnetic fieldsImmune against magnetic DC-field
-
Height of sensor40 mm
-
Mechanical mounting condition for sensorConcise
-
Suitable for safety functionsNo
-
Type of electric connectionScrew connection
-
Number of contact energized outputs with signalling function0
-
Number of protected contact energized outputs0
-
Type of interfaceNone
-
Construction type housingCuboid
-
CascadableNo
-
Performance level according to EN ISO 13849-1None
-
Supply voltage12 ... 48 V
-
Voltage typeAC/DC
-
With monitoring function downstream switching devicesNo
-
Compression-resistantNo
-
Explosion safety category for dustNone
Hersteller-Details
-
HerstellerSchneider Electric Polska Sp. z o.o.
-
Adresse02-673 Warszawa ul. Konstruktorska 12
-
Steueridentifikationsnummer5220011965
