Mixed module (for lighting and motor loads) MH-IO12E6-6

Indice locale:
API083FIFQ
Numero di catalogo:
MH-IO12E6-6
Codice EAN:
5908312595182
Produttore: F&F
Number of inputs: 28
Number of outputs: 24
Maximum voltage [V]: 26
Prezzo:
1744,45 zł
gross / pezzi
(inclusa IVA 23%)
fino a una settimana
Su ordinazione
Quantità pezzi
(multiplo:
1
)
Aggiungi alla richiesta di preventivo
Aggiungi agli appunti
Stampa

Descrizione del prodotto

Mixed module (for lighting and motor receivers)< td>12
Maximum number of switching outputs
Maximum number of shutter outputs12



Dati tecnici

  • Number of inputs
    28
  • Maximum voltage [V]
    26
  • Level of security
    IP20
  • Package height [mm]
    105
  • Package weight [kg]
    0.3
  • PKWIU
    26.30.23.0
  • Number of outputs
    24
  • Family
    F&HOME
  • Dimensions
    6 modules (105mm)
  • Package width [mm]
    130
  • Indicator
    LED

Altri dati tecnici

  • Bus system KNX
    No
  • Bus system radio frequent
    No
  • Bus system Powernet
    No
  • Remote operation possible
    No
  • Mounting method
    Other
  • With bus connection
    Yes
  • With LED indication
    Yes
  • Number of input channels
    28
  • Number of inputs
    28
  • Number of output channels
    24
  • Max. number of venetian-blind outputs
    12
  • Rated operating voltage
    20 ... 26 V
  • Different phases connectable
    No
  • Bus system KNX-RF (Radio Frequent)
    No
  • Bus system LON
    No
  • Other bus systems
    Other
  • Ethernet
    No
  • Width in number of modular spacings
    6
  • LED controlling
    No
  • Local operation/hand operation
    No
  • Number of switch inputs
    12
  • Suitable for C-load
    No
  • Max. number of switching contacts
    12
  • With switch function
    No
  • External signal voltage necessary
    No
  • Degree of protection (IP)
    IP20

Dettagli del produttore

  • Produttore
    F&F Filipowski S.K.
  • Indirizzo
    95-200 Pabianice Konstantynowska 79/81 Polska

Imballaggio sfuso

Una specie di pacchetto Sztuka
Quantità 1 pezzi
Peso (kg) 0,260
Larghezza (m) 0,104
Profondità (m) 0,075
