Name: LED module + varistor 230V AC/DC
Brand: FINDER
SKU: APE027FIND
Price: 3.49 PLN
Availability: InStock

Surge signaling and EMC protection module

LED and varistor modules are used with both DC and alternate. The voltage peaks of the reverse polarity relay coil are limitedby the varistor to approximately 2.5 times the voltage rating of the -silane. When using DC coils, it is important to connect the positive pole to terminal A1. Relay release time increases slightly.

Installation

On the TH-35 rail
Type of voltage

AC/DC
LED color

Green

Rated voltage [V]

230
Family

99

Other technical data

Function

Varistor (voltage-sensitive resistor)
Rated control supply voltage AC 60 Hz

110 ... 240 V
Voltage type for actuating

AC/DC

Rated control supply voltage AC 50 Hz

110 ... 240 V
Rated control supply voltage DC

110 ... 240 V
With LED indication

Yes

A kind of package	Karton	Torebka	Karton
Quantity	1 pcs.	10 pcs.	1000 pcs.
Weight (kg)	0,007	0,040	4,450
Volume (m3)	0,000	0,000	0,025
Width (m)	0,023	0,070	0,340
Length (m)	0,030	0,175	0,390
Depth (m)	0,048	0,010	0,190
