KNX RF quicklink 2-channel radio remote control TU402

local index:
AIK037HAGE
Catalog No:
TU402
EAN code:
3250616014022
Manufacturer: HAGER
Battery: 2x 3V CR2430
Depth [mm]: 15.8
Level of security: IP50
Price:
93,47 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 10 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

KNX RF quicklink 2-channel radio remote control

Technical data

  • Battery
    2x 3V CR2430
  • Level of security
    IP50
  • Height [mm]
    83
  • Radio transmitter/receiver frequency [MHz]
    868.3
  • Number of radio channels
    2
  • Radio protocol
    KNX
  • Radio transmitter range (in open area) [m]
    100
  • PKWIU
    26.51.70.0
  • Depth [mm]
    15.8
  • Width [mm]
    46.5
  • Operating temperature range [°C]
    from -10 to 45
  • Receiver category
    2
  • Radio transmitter power [mA]
    <10
  • Range of the radio transmitter (in the building) [m]
    thirty
  • Battery life [years]
    ≈ 5

Other technical data

  • Wireless
    Yes
  • Height
    83 mm
  • Depth
    15.8 mm
  • With display
    No
  • Width
    46.5 mm
  • Bi-directional
    Yes

Bulk packaging

A kind of package Karton Pakiet Paleta
Quantity 1 pcs. 1 pcs. 60 pcs. 1440 pcs.
Weight (kg) 0,040 0,070 4,845 139,280
Width (m) 0,047 0,080 0,320 0,800
Length (m) 0,085 0,040 0,215 1,050
Depth (m) 0,014 0,100 0,365 1,200
