Blind/roller shutter controller, KNX easy series:

Functions

with positioning function for blinds and slats
with safety functions, e.g. for wind, rain, alarm
with sun protection

Controls and indicators

modular
status LED integrated with manual button
manual up/down buttons for each channel/device
with illuminated programming button

Characteristics of the series:

KNX easy from the company is a new building automation system providing an easy-to-use application in private residential buildings. KNX easy is not only an innovative, fast and inexpensive solution - it is above all a very simple tool. New hardware or costly ETS software are unnecessary. With KNX easy, all you need is the easy server, a mobile device (tablet) and the Easy Tool app. Now you can set up simple and effective building control. KNX easy is a speed of operation that reduces the time you need to spend on programming. The advantages of using an intelligent building control system make its purchase a profitable investment even for an average household. What's more, its modular nature allows you to expand at any time, but you can plan it for your customers in advance and help them reduce costs.

Color

Gray
Level of security

IP20
Operating temperature range [°C]

from -5 to 45
Accurate color

light gray
Maximum operating current [A]

6
Bus current consumption (data transmission) [mA]

5
Beacon

Yes
Supply voltage type

AC
Conductor cross-section (wire) [mm²]

0.75 - 2.5

Family

KNX EASY
Connection type

Quick Connect
Number of modules

4
DC supply voltage [V]

thirty
Operating voltage via DC bus [V]

21 - 32
Manual control

Yes
storage temperature [°C]

from -20 to 70
Wire cross-section (cord) [mm²]

0.75 - 2.5
PKWIU

26.30.23.0

Other technical data

Bus system KNX

Yes
Bus system radio frequent

No
Bus system Powernet

No
Radio frequent bidirectional

No
Width in number of modular spacings

4
Bus module detachable

No
With LED indication

Yes
Switching current (resistive)

6 A
Max. number of venetian-blind outputs

4
Type of current

AC

Bus system KNX-RF (Radio Frequent)

No
Bus system LON

No
Other bus systems

None
Mounting method

DRA (DIN-rail adapter)
With bus connection

Yes
Local operation/hand operation

Yes
Number of inputs

0
Max. switching power

1200 W
With switch function

No
Degree of protection (IP)

IP20

A kind of package		Karton	Pakiet	Paleta
Quantity	1 pcs.	1 pcs.	24 pcs.	576 pcs.
Weight (kg)	0,199	0,280	7,120	193,880
Width (m)	0,069	0,095	0,315	0,800
Length (m)	0,090	0,080	0,245	1,050
Depth (m)	0,071	0,120	0,365	1,200
