Inductive sensor with PNP 1NO 12-24V DC output, M8 connector XS5L81PA140S

local index:
API486SCHN
Catalog No:
XS5L81PA140S
EAN code:
3389110836608
Manufacturer: SCHNEIDER ELECTRIC
Material: Metal
Price:
124,98 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Out of stock
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Print

Product description

Inductive sensor with PNP 1NO 12-24V DC output, M8 connector

Technical data

  • Material
    Metal
  • PKWIU
    26.51.66.0

Other technical data

  • Width sensor
    8 mm
  • Length of sensor
    8 mm
  • Switching distance
    1.5 mm
  • Type of switch function
    Normally open contact
  • Type of electric connection
    Connector M8
  • Number of contact energized outputs with signalling function
    0
  • Number of protected contact energized outputs
    0
  • Type of interface
    None
  • Construction type housing
    Cuboid
  • Cascadable
    No
  • Performance level according to EN ISO 13849-1
    None
  • Supply voltage
    12 ... 24 V
  • Voltage type
    AC/DC
  • With monitoring function downstream switching devices
    No
  • Compression-resistant
    No
  • Explosion safety category for dust
    None
  • Height of sensor
    43 mm
  • Mechanical mounting condition for sensor
    Concise
  • Suitable for safety functions
    No
  • Type of switching output
    PNP/PNP
  • Number of semiconductor outputs with signalling function
    1
  • Number of protected semiconductor outputs
    0
  • Type of actuation
    Metallic Target
  • Type of interface for safety communication
    None
  • Coating housing
    Nickel-plated
  • SIL according to IEC 61508
    None
  • Max. output current at protected output
    200 mA
  • Rated control supply voltage DC
    12 ... 24 V
  • Switching frequency
    2500 Hz
  • Housing material
    Metal
  • Explosion safety category for gas
    None
  • Interference resistance to magnetic fields
    Immune against magnetic DC-field

Manufacturer details

  • Manufacturer
    Schneider Electric Polska Sp. z o.o.
  • Address
    02-673 Warszawa ul. Konstruktorska 12
  • Tax identification number
    5220011965
