Harmony Relay Solid State Relay DIN Rail Mount 4/32VDC Input 24/280VAC 30A Output SSM1A130BD

local index:
APE065SCHN
Catalog No:
SSM1A130BD
EAN code:
3606485441580
Price:
135,36 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Out of stock
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Print

Product description

Harmony Relay Solid State Relay DIN Rail Mount 4/32VDC Input 24/280VAC 30A Output

Technical data

  • PKWIU
    27.11.61.0

Other technical data

  • Rated control supply voltage AC 50 Hz
    24 ... 280 V
  • Rated control supply voltage DC
    4 ... 32 V
  • Operating voltage
    24 ... 280 V
  • Rated operation current Ie at AC-3
    30 A
  • Rated operation current Ie at AC-53a
    30 A
  • Number of phases
    1
  • Switching at zero-crossing
    no
  • Rated control supply voltage AC 60 Hz
    24 ... 280 V
  • Voltage type for actuating
    AC/DC
  • Rated operation current Ie at AC-1
    30 A
  • Rated operation current Ie at AC-51
    30 A
  • Rated operation current Ie at AC-53b
    30 A
  • Modular version
    yes
