Five-channel DIN rail relay LongRange rH-R5-LR RH-R5-LR

local index:
APS017FIFQ
Catalog No:
RH-R5-LR
EAN code:
5908312597858
Manufacturer: F&F
Number of outputs: 5
Output current [A]: 10
Family: F&HOME RADIO
Price:
146,31 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to a week (working days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description


The rH-R5 LR module contains five relays for switching electric circuits from a common power supply. Communication with the server takes place via radio. The load of the relay contacts can be resistive, inductive or capacitive, both in DC and AC circuits. All relays have one output of the NO contact connected to a common wire. The module has a much greater transmission range (up to 300m) compared to the equivalent rH-R5 F2250.

Technical data

  • Number of outputs
    5
  • Family
    F&HOME RADIO
  • Package height [mm]
    80
  • Package weight [kg]
    0.3
  • Indicator
    LED
  • Output current [A]
    10
  • Level of security
    IP20
  • Package width [mm]
    80
  • Output current [A]
    10
  • PKWIU
    27.12.24.0

Other technical data

  • Bus system KNX
    No
  • Bus system radio frequent
    No
  • Bus system Powernet
    No
  • Mounting method
    DRA (DIN-rail adapter)
  • Model
    Base module
  • Number of outputs
    5
  • Degree of protection (IP)
    IP20
  • Bus system KNX-RF (Radio Frequent)
    No
  • Bus system LON
    No
  • Other bus systems
    Other
  • Width in number of modular spacings
    3
  • With LED indication
    Yes
  • Output voltage
    12 ... 250 V

Bulk packaging

A kind of package Sztuka
Quantity 1 pcs.
Weight (kg) 0,220
