The regulator performs the selected operating function based on individual entries of temperature, hysteresis, activation delay and other parameters entered by the user.
Technical data
Hysteresis - adjustable
0-100
Power [W]
1.5
Rated voltage [V]
230
Wire
PC3×0.34mm; l=1.5m in a metal braid
Contact
1P separated
Dimensions
3 modules (52.5mm)
Package height [mm]
150
Package weight [kg]
0.25
Temperature probe
RT-56
Sensor insulation
Steel sleeve
Installation
On the TH-35 rail
load current [A]
<16
connection
2.5mm screw terminals
Working temperature [°C]
-60
Temperature adjustment range [°C]
-500
Package width [mm]
60
Standard Correction
±20
PKWIU
26.51.70.0
Other technical data
Model
Digital
Rated voltage
230 ... 230 V
Number of channels
1
24 h program
Yes
Number of memory locations
1
Input for time program
No
Autonomy
0 h
Operation mode switch
Yes
Contact type
Change-over contact
Nominal switching current at 230 V, not potential free
16 A
Width in number of modular spacings
3
Sensor type
Remote sensor
Rated frequency
50 ... 50 Hz
Text guidance in display
Yes
Weekly program
Yes
Holiday program
No
Adjustment range set-back
0 ... 100 °C
Automatic switching summer-/winter time
Yes
Switching preselection
No
Nominal switching current at 250 V, potential free
