Automatic staircase ASO-42 ASO-42
local index:
API091FIFQ
Catalog No:
ASO-42
EAN code:
5908312590101
Manufacturer:
F&F
Maximum switching capacity for bulbs [W]: 1500
Control voltage [V]: 42
Dimensions: 2 modules (36mm)
Price:
97,86 zł
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to inquiry
Add to clipboard
Print
Ask about the product
Product description
Purpose:
Staircase automatics are used to keep the lighting of corridors, staircases or other objects on for a specified period of time, after which the lighting will be switched off automatically.
Operation
Automators cannot work directly with fluorescent lamps, compact fluorescent lamps and other lamps with electronic starters.
Technical data
-
Maximum switching capacity for bulbs [W]1500
-
Dimensions2 modules (36mm)
-
Package width [mm]40
-
Maximum switching capacity for fluorescent lamps [VA]350
-
Trigger delay [min]0.5/10
-
PKWIU27.12.23.0
-
Control voltage [V]42
-
Package height [mm]150
-
Package weight [kg]0.2
-
Shutdown warningTotal dimming
-
Rated inrush current [A]10
Other technical data
-
FunctionElectronic
-
Width in number of modular spacings0
-
Number of contacts as normally open contact1
-
Number of contacts as change-over contact0
-
Type of control voltage 1AC/DC
-
Rated switch current1.5 A
-
Release-delay0.5 ... 10 min
-
Wiring system3 wire configuration
-
RepetitiveRepetitive + continuous light
-
Voltage type (supply voltage)AC/DC
-
Max. load fluorescent lamp0 VA
-
Max. load fluorescent lamp (parallel compensated)0 VA
-
Power consumption0.56 W
-
Mounting methodSurface mounted
-
Built-in depth0 mm
-
Number of contacts as normally closed contact0
-
Control voltage 138 ... 46 V
-
Frequency control voltage 10 ... 50 Hz
-
Max. switching current (cos phi = 0.6)1 A
-
Push button glow-lamp current0 mA
-
Pre-warning of switching-offNone
-
Supply voltage38 ... 46 V
-
Max. incandescent lamp load350 W
-
Max. load fluorescent lamp (Duo circuit)0 VA
-
Max. switching power LED150 W
Manufacturer details
-
ManufacturerF&F Filipowski S.K.
-
Address95-200 Pabianice Konstantynowska 79/81 Polska
-
E-mail
Bulk packaging
| A kind of package | Sztuka |
| Quantity | 1 pcs. |
| Weight (kg) | 0,082 |
| Width (m) | 0,030 |
| Length (m) | 0,095 |
| Depth (m) | 0,070 |
