el12 Automation Relays and drivers Other automation elements

8-channel RTD analog input, light gray 750-451

Indice locale:
API079WAGO
Numero di catalogo:
750-451
Codice EAN:
4017332258388
8-channel RTD analog input, light gray
8-channel RTD analog input, light gray
8-channel RTD analog input, light gray
8-channel RTD analog input, light gray

Clicca sulla foto per ingrandire

Produttore: WAGO ELWAG
Prezzo:
1 530,12 zł
gross / pezzi
(inclusa IVA 23%)
fino a 4 settimane
Su ordinazione
Quantità pezzi
(multiplo:
1
)
Aggiungi alla richiesta di preventivo
Aggiungi agli appunti
Stampa
Dati tecnici Dettagli del produttore Imballaggio sfuso

Dati tecnici

Altri dati tecnici

  • Supply voltage DC
    24 ... 24 V
  • Power consumption
    1 W
  • Input, voltage
    No
  • Input, resistance thermometer
    No
  • Input signal, configurable
    Yes
  • Output, current
    No
  • Output signal configurable
    No
  • Number of analogue outputs
    0
  • Analogue outputs configurable
    No
  • Number of interfaces PROFINET
    0
  • Number of HW-interfaces RS-422
    0
  • Number of HW-interfaces serial TTY
    0
  • Number of HW-interfaces wireless
    0
  • Number of HW-interfaces other
    0
  • Supporting protocol for TCP/IP
    No
  • Supporting protocol for CAN
    No
  • Supporting protocol for ASI
    No
  • Supporting protocol for Modbus
    No
  • Supporting protocol for DeviceNet
    No
  • Supporting protocol for LON
    No
  • Supporting protocol for PROFINET CBA
    No
  • Supporting protocol for Foundation Fieldbus
    No
  • Supporting protocol for AS-Interface Safety at Work
    No
  • Supporting protocol for INTERBUS-Safety
    No
  • Supporting protocol for SafetyBUS p
    No
  • Radio standard Bluetooth
    No
  • Radio standard GPRS
    No
  • Radio standard UMTS
    No
  • System accessory
    Yes
  • Type of electric connection
    Spring clamp connection
  • Rail mounting possible
    Yes
  • Front built-in possible
    No
  • Suitable for safety functions
    No
  • Performance level according to EN ISO 13849-1
    None
  • Appendant operation agent (Ex ib)
    No
  • Explosion safety category for dust
    ATEX dust-ex-protection, Cat. 3D
  • Certified for UL hazardous location class II
    No
  • Certified for UL hazardous location division 1
    Yes
  • Certified for UL hazardous location group A (acetylene)
    Yes
  • Certified for UL hazardous location group C (ethylene)
    Yes
  • Certified for UL hazardous location group E (metal dusts)
    No
  • Certified for UL hazardous location group G (non-conductive dusts)
    No
  • Height
    100 mm
  • Voltage type (supply voltage)
    DC
  • Input, current
    No
  • Input, resistor
    Yes
  • Input, thermocouple
    No
  • Resolution of the analogue inputs
    16 b
  • Output, voltage
    No
  • Number of analogue inputs
    8
  • Analogue inputs configurable
    No
  • Number of HW-interfaces industrial Ethernet
    0
  • Number of HW-interfaces RS-232
    0
  • Number of HW-interfaces RS-485
    0
  • Number of HW-interfaces parallel
    0
  • Number of HW-interfaces USB
    0
  • Supporting protocol for EtherCAT
    No
  • Supporting protocol for PROFIBUS
    No
  • Supporting protocol for INTERBUS
    No
  • Supporting protocol for KNX
    No
  • Supporting protocol for Data-Highway
    No
  • Supporting protocol for SUCONET
    No
  • Supporting protocol for PROFINET IO
    No
  • Supporting protocol for SERCOS
    No
  • Supporting protocol for EtherNet/IP
    No
  • Supporting protocol for DeviceNet Safety
    No
  • Supporting protocol for PROFIsafe
    No
  • Supporting protocol for other bus systems
    No
  • Radio standard WLAN 802.11
    No
  • Radio standard GSM
    No
  • IO link master
    No
  • Degree of protection (IP)
    IP20
  • Fieldbus connection over separate bus coupler possible
    Yes
  • Wall mounting/direct mounting
    No
  • Rack-assembly possible
    No
  • SIL according to IEC 61508
    None
  • Appendant operation agent (Ex ia)
    No
  • Explosion safety category for gas
    ATEX gas-ex-protection, Cat. 3G
  • Certified for UL hazardous location class I
    Yes
  • Certified for UL hazardous location class III
    No
  • Certified for UL hazardous location division 2
    No
  • Certified for UL hazardous location group B (hydrogen)
    Yes
  • Certified for UL hazardous location group D (propane)
    Yes
  • Certified for UL hazardous location group F (carbonaceous dusts)
    No
  • Width
    12 mm
  • Depth
    69 mm

Dettagli del produttore

  • Produttore
    WAGO GmbH & Co. KG
  • Indirizzo
    32423 Minden Hansastraße 27 Niemcy
  • Email
    wago.elwag@wago.com

Imballaggio sfuso

Una specie di pacchetto Karton
Quantità 1 pezzi
Peso (kg) 0,063
Volume (m3) 0,000
Larghezza (m) 0,020
Lunghezza (m) 0,104
Profondità (m) 0,074
