el12 Power sources transformers Safety and separation transformers Single-phase transformer TMM 100/A 230/230V
Single-phase transformer TMM 100/A 230/230V
Single-phase transformer TMM 100/A 230/230V

Click on the photo to enlarge

Single-phase transformer TMM 100/A 230/230V
Single-phase transformer TMM 100/A 230/230V
BREVE

Single-phase transformer TMM 100/A 230/230V 16252-9990

local index:
AUP063BREV
Catalog No:
16252-9990
EAN code:
5907812711955
Price:
60,26 €
gross / pcs.
including VAT 23%
Availability:
up to 2 weeks (business days)
Delivery:
From 3,68 € (prepaid courier) Details
Quantity:
Goods at a promotional price can only be purchased in the quantity available in stock pcs.
Delivery methods:
Metody dostawy
details
Payment methods:
Metody płatności
details
Go to section:
Product description Technical data

Product description

Single-phase open (IP00) isolation or safety transformers, intended for general use and built-in in industrial or
electric power installations and devices.
I insulation class and IP00 protection, max. ambient temperature 40°C.
Made according to EN 61558-2-4, EN 61558-2-6.
Print the product sheet Report an error

Technical data

  • Length [mm]
    84
  • Maximum ambient temperature [°C]
    40
  • Primary voltage [V]
    230
  • Mounting method
    For screws
  • Width [mm]
    84
  • Primary winding [V]
    230
  • Mounting thread
    M4
  • Depth [mm]
    100
  • Power [VA]
    100
  • Secondary voltage [V]
    230
  • Level of security
    IP00
  • Height [mm]
    74
  • Secondary winding [V]
    230

Other technical data

  • Built as safety transformer
    no
  • Built as energy saving transformer
    no
  • Secondary voltage 1
    230 ... - V
  • Type of insulation material according to IEC 85
    B
  • Width
    84 mm
  • Depth
    100 mm
  • Ring core
    no
  • Modular version
    no
  • Built as isolating transformer
    yes
  • Primary voltage 1
    230 ... - V
  • Rated apparent power
    100 VA
  • Short-circuit-proof
    no
  • Height
    74 mm
  • Degree of protection (IP)
    IP00
  • Suitable for mounting on PCB
    no
