el12 Electrical apparatus RCDs Electric shock switches Residual current device, CFI6-25/2/003-DE
Residual current device, CFI6-25/2/003-DE
Residual current device, CFI6-25/2/003-DE
Residual current device, CFI6-25/2/003-DE
Residual current device, CFI6-25/2/003-DE
Residual current device, CFI6-25/2/003-DE

Click on the photo to enlarge

Residual current device, CFI6-25/2/003-DE
Residual current device, CFI6-25/2/003-DE
Residual current device, CFI6-25/2/003-DE
Residual current device, CFI6-25/2/003-DE
Residual current device, CFI6-25/2/003-DE
EATON

Residual current device, CFI6-25/2/003-DE 235753

local index:
ARP122MOEL
Catalog No:
235753
EAN code:
4015082357535
Price:
26,81 €
gross / pcs.
including VAT 23%
Availability:
Lack
Delivery:
From 3,47 € (prepaid courier) Details
Quantity:
Goods at a promotional price can only be purchased in the quantity available in stock pcs.
Delivery methods:
Metody dostawy
details
Payment methods:
Metody płatności
details
Go to section:
Product description Technical data

Product description


Rated voltage 230V/400V

Sensitive to alternating current AC 30mA

Rated current 25A

Number of poles: 2< br />
Optical ON/OFF status indicator

Tripping independent of mains voltage

Short-circuit resistance 6kA with 63A fuse gL/gG

temp. -25 to +40 C

Possibility of adding additional equipment

Print the product sheet Report an error

Technical data

  • Tenderness
    AC
  • Differential current [mA]
    thirty
  • Number of poles
    2
  • Rated current [A]
    25

Other technical data

  • Number of poles
    2
  • Rated current
    25 A
  • Rated insulation voltage Ui
    440 V
  • Mounting method
    DIN rail
  • Selective protection
    no
  • Short-circuit breaking capacity (Icw)
    6 kA
  • Frequency
    50 Hz
  • With interlocking device
    yes
  • Width in number of modular spacings
    2
  • Ambient temperature during operating
    -25 ... 55 °C
  • Connectable conductor cross section multi-wired
    1.5 ... 16 mm²
  • Rated voltage
    230 V
  • Rated fault current
    30 mA
  • Rated impulse withstand voltage Uimp
    4 kV
  • Leakage current type
    AC
  • Short-time delayed tripping
    no
  • Surge current capacity
    0.25 kA
  • Additional equipment possible
    yes
  • Degree of protection (IP)
    IP20
  • Built-in depth
    69.5 mm
  • Pollution degree
    2
  • Connectable conductor cross section solid-core
    1.5 ... 35 mm²
