el12 Electrical apparatus RCDs Electric shock switches RCCB 4P 80A/30mA Type A Residual Current Circuit Breaker
RCCB 4P 80A/30mA Type A Residual Current Circuit Breaker

Click on the photo to enlarge

RCCB 4P 80A/30mA Type A Residual Current Circuit Breaker
HAGER

RCCB 4P 80A/30mA Type A Residual Current Circuit Breaker CD480D

local index:
ARP030HAGE
Catalog No:
CD480D
EAN code:
3250611647690
Price:
537,88 €
gross / pcs.
including VAT 23%
Availability:
Lack
Delivery:
From 3,68 € (prepaid courier) Details
Quantity:
Goods at a promotional price can only be purchased in the quantity available in stock pcs.
Delivery methods:
Metody dostawy
details
Payment methods:
Metody płatności
details
Go to section:
Product description Technical data

Product description

RCCB 4P 80A/30mA Type A Residual Current Circuit Breaker
Print the product sheet Report an error

Technical data

  • Rated frequency [Hz]
    50
  • Number of poles
    4
  • Rated insulation voltage [V]
    500
  • Rated current [A]
    80
  • power loss [W]
    19.7
  • Width [mm]
    70
  • Height [mm]
    86
  • Mechanical durability (number of cycles)
    4000
  • Rated switching voltage [V]
    230/400
  • Number of modules
    4
  • Rated current at 30°C [A]
    80
  • Rated current at 45°C [A]
    80
  • Rated current at 55°C [A]
    80
  • Rated current at 65°C [A]
    71
  • storage temperature [°C]
    from -55 to 70
  • Number of protected poles
    4
  • Conductor cross-section (wire) [mm²]
    50
  • Depth [mm]
    70
  • Tightening torque [Nm]
    3.3
  • Differential current [mA]
    thirty
  • Level of security
    IP20
  • Power loss per pole [W]
    7.4
  • Connection type
    With a screw
  • Electrical endurance (number of cycles)
    2000
  • Operating temperature range [°C]
    from -25 to 40
  • Rated impulse voltage [kV]
    4
  • Rated current at 20°C [A]
    80
  • Rated current at 40°C [A]
    80
  • Rated current at 50°C [A]
    80
  • Rated current at 60°C [A]
    75
  • Rated current at 70°C [A]
    59
  • RCD type
    AND
  • Wire cross-section (cord) [mm²]
    35

Other technical data

  • Number of poles
    4
  • Rated current
    80 A
  • Rated insulation voltage Ui
    500 V
  • Mounting method
    DIN rail
  • Selective protection
    no
  • Short-circuit breaking capacity (Icw)
    6 kA
  • Frequency
    50 Hz
  • With interlocking device
    yes
  • Width in number of modular spacings
    4
  • Ambient temperature during operating
    -25 ... 40 °C
  • Connectable conductor cross section multi-wired
    1 ... 35 mm²
  • Rated voltage
    400 V
  • Rated fault current
    30 mA
  • Rated impulse withstand voltage Uimp
    4 kV
  • Leakage current type
    A
  • Short-time delayed tripping
    no
  • Surge current capacity
    0.25 kA
  • Additional equipment possible
    yes
  • Degree of protection (IP)
    IP20
  • Built-in depth
    70 mm
  • Pollution degree
    2
  • Connectable conductor cross section solid-core
    1 ... 50 mm²
