el12 Automation Circuit breakers, disconnectors Switches up to 160A Double switch FR 322 20 A
Double switch FR 322 20 A
Double switch FR 322 20 A

Click on the photo to enlarge

Double switch FR 322 20 A
Double switch FR 322 20 A
LEGRAND

Double switch FR 322 20 A 412903

local index:
ALI135LEGR
Catalog No:
412903
EAN code:
3414970531490
Price:
34,87 €
gross / pcs.
including VAT 23%
Availability:
up to 2 weeks (business days)
Delivery:
From 3,47 € (prepaid courier) Details
Quantity:
Goods at a promotional price can only be purchased in the quantity available in stock pcs.
Delivery methods:
Metody dostawy
details
Payment methods:
Metody płatności
details
Go to section:
Product description Technical data

Product description

Equipped with a window to describe the device
Operating category: AC 22 A according to IEC 60947-3
Compliant with EN / IEC 60669-1




Switches
Dual switch with mid-neutral point
Rated voltage 400 V~
Rated current: 20 A
Width in 17.5 mm modules: 1
Print the product sheet Report an error

Technical data

  • Level of security
    IP20

Other technical data

  • Switching function
    Two-way switch
  • Number of contacts as normally closed contact
    0
  • Rated current
    32 A
  • Min. rated voltage
    380 V
  • Voltage type
    AC
  • Colour calotte
    Other
  • Lamp socket
    Other
  • Built-in depth
    44 mm
  • Number of contacts as normally open contact
    0
  • Number of contacts as change-over contact
    2
  • Rated voltage
    400 V
  • Short-circuit breaking capacity (Icw)
    0.384 kA
  • With signal lamp
    no
  • Lamp type
    Other
  • Width in number of modular spacings
    2
  • Degree of protection (IP)
    IP20

Catalog cards, diagrams, certificates

F02021EN_03.pdf
LGRP-2015-286-V1-EN.pdf
